उत्पाद विवरण:
|
| प्रमुखता देना: | 5μm Filtration Precision Stainless Steel Filter,40μm Optional Filtration Pneumatic Filter,G1/8 to G1 Connection Air Filter |
||
|---|---|---|---|
| Model | QSLH-06 | QSLH-08 | QSLH-10 | QSLH-15 | QSLH-20 | QSLH-25 |
|---|---|---|---|---|---|---|
| Fluid Application | Compressed air | |||||
| Connection Bore | G1/8 | G1/4 | G3/8 | G1/2 | G3/4 | G1 |
| Pressure Regulation Structure | Piston Type | |||||
| QSLH | B | 15 | N | C | H | W |
|---|---|---|---|---|---|---|
| Series Number | Pressure | Connection Port Diameter | Connection Port Thread | Filtration Precision | Drainage Method | Visual Window |
| Stainless Steel Filter | Blank: 12 - 28kgf/cm² B: 0.5 - 12kgf/cm² |
06: G1/8" 08: G1/4" 10: G3/8" 15: G1/2" 20: G3/4" 25: G1" |
Blank: G N: NPT R: Rc |
PE Filter Element Blank: 5μm C: 40μm |
Blank: Semi-automatic Drainage H: Manual Drainage D: Automatic Drainage |
Blank: None |
