उत्पाद विवरण:
|
| प्रमुखता देना: | stainless steel pressure reducing valve,QTYH Series pressure valve,industrial pressure regulator with warranty |
||
|---|---|---|---|
| model | QTYH-08 | QTYH-10 | QTYH-15 | QTYH-20 | QTYH-25 | QTYH-32 | QTYH-40 | QTYH-50 |
| Using fluids | compressed air | |||||||
| takeover caliber | G1/4 | G3/8 | G1/2 | G3/4 | G1 | G13/8 | G11/2 | G2 |
| Pressure regulating structure | piston-type | |||||||
| body material | Stainless steel SUS316 | |||||||
| Pressure gauge material | Shell made of stainless steel SUS304, teeth made of stainless steel SUS316 | |||||||
| Operating pressure | QTYHB:0.5-12kgf/cm2, QTYH:12-28kgf/cm2 | |||||||
| Maximum intake pressure | 60kgf/cm2 | |||||||
| ambient temperature | -10-70°C | |||||||
| Accessory parts | Pressure gauge (0-40kg), plug | |||||||
| optional | Pressure gauge (0~40kg), pressure gauge (0~60kg) | |||||||
| QTYH | B | 15 | N |
| serial number | pressure | takeover caliber | Pipe mouth screw thread |
| Stainless steel pressure reducing valve | Blank: 12-28kgf/cm | 08:G1/4;25:G1" | Blank: G |
| B:0.5-12kgf/cm2 | 10:G3/8;32:G13/8 | N:NPT | |
| 15:G1/2";40:G11/2 | R:Rc | ||
| 20:G3/4;50:G2 |
