उत्पाद विवरण:
|
| नमूना: | SMF19 | आकार: | 1pc 2pcs 5pcs |
|---|---|---|---|
| प्रमाणन: | ce | स्विच प्रकार: | प्रेशर स्विच |
| सामग्री: | एल्यूमिनियम मिश्र धातु | धागा: | जी एनपीटी |
| प्रमुखता देना: | वायु कंप्रेसर पंप दबाव स्विच,1/4 जी एनपीटी दबाव स्विच,विश्वसनीय नियंत्रण दबाव स्विच |
||
Ex : ON :1Bar OFF:2Bar =NC
ON :2Bar OFF:1Bar =NO
ON :-0.9Bar OFF:-0.65Bar =NO
ON :-0.65Bar OFF:-0.9Bar =NC
SMF19 pressure switches can also be used to regulate the tank pressure between two preset values on onephase electrically driven air compressors. They are available with an unloader valve, which prevents compressors from starting under load, and it is available with an On-Off knob for manual cut off the compressor.
|
MODEL
|
Media
|
Unloader
Valve
|
Operating
Pressure Range(bar)
|
Factory Setting
(bar)
|
Differential
(bar)
|
Electrical Rating
|
Contact Arrangement
|
|
SMF19
|
Air
|
with
|
1-6
|
1-3
|
2-4
|
16A ,25/250VAC
|
NC
|
|
2-11
|
1.4-3.5
|
6-8
|
|||||
|
5-14
|
1.8-4.0
|
8-10
|
