उत्पाद विवरण:
|
| कोड: | 706 DN25 | आकार: | A 90 B 20 C 92 D 152 D1 65 D2 85 4-D 4-φ14 |
|---|---|---|---|
| गैर -स्पंदित काम का दबाव: | 2.5MPA | संतृप्त भाप: | 0.8MPA |
| कार्य माध्यम: | पानी, गैस, तेल | गारंटी: | 1 वर्ष |
| प्रमुखता देना: | 2.5MPa स्टील बॉल वाल्व,गैर-स्पंदनशील स्टील बॉल वाल्व,जल माध्यम स्टील बॉल वाल्व |
||
Generally installed on boilers, between the water level alarm and the water level gauge, the total length of the ball valve is only 90mm. The 706 steel ball valve has no pulsation working pressure: normal temperature water, gas, oil: 2.5MPa; Saturated steam: 0.8MPaDNABCDD1D24-d2590209215265854- φ 14 steel body ball valve. Currently, the most commonly used main materials in China are mainly divided into four categories: ordinary carbon steel (WCB, WCC, etc.), ordinary low-temperature steel (LCB, LC2, LC3, etc.), and high-temperature steel (WC6, WC9, ZG15Cr1MoG, etc.)
| 706 | Non pulsating working pressure: room temperature water, gas, oil: 2.5MPa; Saturated steam: 0.8MPa | ||||||
| DN | A | B | C | D | D1 | D2 | 4-d |
| 25 | 90 | 20 | 92 | 152 | 65 | 85 | 4-φ14 |
