उत्पाद विवरण:
|
| कोड: | TL103-15 TL103-20 | आकार (मिमी): | D1 1/2 "3/4" |
|---|---|---|---|
| नाम का हिस्सा: | वाल्व बॉडी सीलिंग एलिमेंट हैंडल | सामग्री: | ब्रास पीटीएफई |
| नाममात्र दबाव: | 0.6MPA | शक्ति परीक्षण दबाव: | 1.0MPA |
| सील परीक्षण दबाव: | 0.6MPA | प्रचालन तापमान: | ≤200 ℃ |
| कार्य माध्यम: | पानी, भाप, तेल | ||
| प्रमुखता देना: | D1 1/2 ̊ तरल स्तर मापक,तरल स्तर गेज सीलिंग तत्व,तीन हैंडल तरल स्तर गेज |
||
This level gauge (also known as a water level gauge) is suitable for water, steam, and reservoirs with a working temperature t ≤ 200 ℃, and is used to indicate the level of liquid through a glass tube. 103 X29F-6T type code: 103 X29F-6T type (three handles/pair) water level gauge main parts material part name material valve body brass seal polytetrafluoroethylene (plastic king) handle forged steel main technical parameters nominal pressure PN0.6MPa strength test pressure 1.0 sealing test pressure 0.6 working temperature ≤ 200 ℃ working medium: water, steam, oil
| code | size(mm) | Part name | material | |||
| D1 | D2 | L1 | L2 | valve body | brass | |
| TL103-15 | 1/2" | 14 | 87 | 25 | Sealing element | PTFE |
| TL103-20 | 3/4" | 19 | 95 | 30 | handle | forged steel |
| Nominal pressure | 0.6Mpa | |||||
| strength test pressure | 1.0Mpa | |||||
| Seal test pressure | 0.6Mpa | |||||
| operation temperature | ≤200℃ | |||||
| Working medium | Water, steam, oil | |||||
